www.binder-connector.com MAGNETVENTILSTECKVERBINDER SOLENOID VALVE CONNECTORS
Size A 210 Series • Connectors according to DIN EN 175301-803 (replaces 43650) • Connectors moulded on cable • Degree of protection IP65/IP67 • Field wireable • Wired versions Bauform A Serie 210 • Steckverbinder nach DIN EN 175301-803 (ersetzt 43650) • Steckverbinder umspritzt am Kabel • Schutzart IP65/IP67 • Konfektionierbar • Beschaltete Versionen Weitere Informationen unter www.binder-connector.com/More information on www.binder-connector.com Bereich Range Serie Series Seite Page Schutzart Degree of protection Spannung Voltage Strom Current Polzahl No. of contacts Automatisierungstechnik – Magnetventilsteckverbinder Automation Technology – Solenoid Valve Connectors Bauform A Size A 210 4 – 21 IP65/IP67 60/250 V 2–10 A 2–3+PE Inhaltsverzeichnis Contents Übersicht Summary 2
Anschlussart Termination am Kabel angespritzt moulded connectors Verriegelung Locking EMV EMC Ø in mm Ø in mm löten solder tauchlöten dip solder SMT SMT schrauben screw crimpen crimp Käfigzugfeder Wire clamp Schneidklemm IDT schrauben screw Bajonett Bayonet schnapp snap-in Push-Pull Push-Pull — — • • • • M3 3
Magnetventilsteckverbinder Solenid Valve Connectors
5 Gerätesteckdosen Magnetventilsteckdosen Verbindungsleitungen • DIN EN 175301-803 • 2+PE, 3+PE • Niedriges und hohes Gehäuse • Schutzart IP65/IP67 1) • Beschaltete Varianten • Am Kabel angespritzte Ausführungen Female Power Connectors Female Solenoid Valve Connectors Connecting Cables • DIN EN 175301-803 • 2+PE, 3+PE • Low and high housing • Degree of protection IP65/IP67 1) • Wired versions • Moulded versions Automatisierungstechnik - Bauform A Automation Technology - Size A 1) Erläuterung der Schutzarten siehe technische Informationen./ 1) Explanation of protection standards see technical information. 210
6 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology Polzahl Contacts Kabeldurchlass Cable outlet Bestell-Nr. Ordering-No. 2+PE 6–8 mm 43 1700 000 03 3+PE 6–8 mm 43 1702 000 04 Polzahl Contacts Kabeldurchlass Cable outlet Bestell-Nr. Ordering-No. 2+PE 3–10 mm 43 1700 004 03 3+PE 3–10 mm 43 1702 004 04 Gerätesteckdose DIN EN 175301-803, niedriges Gehäuse Female power connector DIN EN 175301-803, low housing Gerätesteckdose DIN EN 175301-803, niedriges Gehäuse, metrisches Gewinde M16 Female power connector DIN EN 175301-803, low housing, metric thread M16 210 Bauform A 40 ~ 50 M3 27 18 1 2 3 26,5 40 ~ 50 M3 27 18 1 2 3 26,5 2+PE 3+PE Zentralschraube/central screw (40 cNm) schrauben/screw (40 cNm) max. 1,5 mm2 (max. AWG 16) 6–8 mm, 3–10 mm IP40 ohne Dichtung/without sealing, IP65 mit Dichtung siehe Zubehör/with sealing see accessories > 50 Steckzyklen/> 50 mating cycles + 125 °C mit Dichtung/with seal 16 8088 000 – 30 °C mit Dichtung/with seal 16 8088 000 250 V 4000 V 3 IIl lll 10 A CuSn (Bronze/bronze) Ni (Nickel/nickel) PA PA Stahl (UQST 36-2 4.8) vernickelt/steel nickel plated
7 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology 40 ~ 50 M3 27 18 1 2 3 26,5 Polzahl Contacts Kabeldurchlass Cable outlet Bestell-Nr. Ordering-No. 2+PE 6–8 mm 43 1770 006 03 3+PE 6–8 mm 43 1772 006 04 Polzahl Contacts Kabeldurchlass Cable outlet Bestell-Nr. Ordering-No. 2+PE 8–10 mm 43 1700 002 03 3+PE 8–10 mm 43 1702 002 04 Gerätesteckdose mit Zugentlastung DIN EN 175301-803, niedriges Gehäuse Female power connector with strain relief DIN EN 175301-803, low housing Gerätesteckdose DIN EN 175301-803, niedriges Gehäuse Female power connector DIN EN 175301-803, low housing 210 Bauform A 40 ~ 50 M3 27 18 1 2 3 26,5 2+PE 3+PE Zentralschraube/central screw (40 cNm) schrauben/screw (40 cNm) max. 1,5 mm2 (max. AWG 16) 6–8 mm, 8–10 mm IP40 ohne Dichtung/without sealing, IP65 mit Dichtung siehe Zubehör/with sealing see accessories > 50 Steckzyklen/> 50 mating cycles + 125 °C mit Dichtung/with seal 16 8088 000 – 30 °C mit Dichtung/with seal 16 8088 000 250 V 4000 V 3 IIl lll 10 A CuSn (Bronze/bronze) Ni (Nickel/nickel) PA PA Stahl (UQST 36-2 4.8) vernickelt/steel nickel plated
8 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology Polzahl Contacts Kabeldurchlass Cable outlet Bestell-Nr. Ordering-No. 2+PE 3–10 mm 43 1704 004 03 3+PE 3–10 mm 43 1706 004 04 Polzahl Contacts Kabeldurchlass Cable outlet Bestell-Nr. Ordering-No. 2+PE 8–10 mm 43 1704 002 03 3+PE 8–10 mm 43 1706 002 04 Polzahl Contacts Kabeldurchlass Cable outlet Bestell-Nr. Ordering-No. 2+PE 6–8 mm 43 1704 000 03 3+PE 6–8 mm 43 1706 000 04 210 Bauform A 2+PE 3+PE Zentralschraube/central screw (40 cNm) schrauben/screw (40 cNm) max. 1,5 mm2 (max. AWG 16) 6–8 mm, 8–10 mm, 3–10 mm IP40 ohne Dichtung/without sealing, IP65 mit Dichtung siehe Zubehör/with sealing see accessories > 50 Steckzyklen/> 50 mating cycles + 125 °C mit Dichtung/with seal 16 8088 000 – 30 °C mit Dichtung/with seal 16 8088 000 250 V 4000 V 3 IIl lll 10 A CuSn (Bronze/bronze) Ni (Nickel/nickel) PA PA Stahl (UQST 36-2 4.8) vernickelt/steel nickel plated Gerätesteckdose DIN EN 175301-803, hohes Gehäuse Female power connector DIN EN 175301-803, high housing Gerätesteckdose DIN EN 175301-803, hohes Gehäuse, metrisches Gewinde M16 Female power connector DIN EN 175301-803, high housing, metric thread M16 Gerätesteckdose DIN EN 175301-803, hohes Gehäuse Female power connector DIN EN 175301-803, high housing 40 ~ 50 27 18 1 2 3 33 M3
9 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology 40 ~ 50 27 18 1 2 3 33 M3 Polzahl Contacts Kabeldurchlass Cable outlet Fast-on Hülse Fast-on sleeve Bestell-Nr. Ordering-No. 2+PE 6–8 mm 0,5 mm2 – 1,0 mm2 43 1708 011 00 1,0 mm2 – 2,5 mm2 43 1708 012 00 8–10 mm 0,5 mm2 – 1,0 mm2 43 1708 013 00 1,0 mm2 – 2,5 mm2 43 1708 014 00 3+PE 6–8 mm 0,5 mm2 – 1,0 mm2 43 1708 015 00 1,0 mm2 – 2,5 mm2 43 1708 016 00 8–10 mm 0,5 mm2 – 1,0 mm2 43 1708 017 00 Gerätesteckdose DIN EN 175301-803, hohes Gehäuse, mit 6,3 mm Fast-on Crimpkontakten Female power connector DIN EN 175301-803, high housing, with 6,3 mm fast-on crimp contacts 210 Bauform A 2+PE 3+PE Zentralschraube/central screw (40 cNm) crimpen/crimp Fast-on Hülse/fast-on sleeve 0,5 mm2 – 1,0 mm2 (AWG 20–AWG 17), 1,0 mm2 – 2,5 mm2 (AWG 16–AWG 14) 6–8 mm, 8–10 mm IP40 ohne Dichtung/without sealing, IP65 mit Dichtung siehe Zubehör/with sealing see accessories > 50 Steckzyklen/> 50 mating cycles + 125 °C mit Dichtung/with seal 16 8088 000 – 30 °C mit Dichtung/with seal 16 8088 000 250 V 4000 V 3 IIl lll 10 A CuSn (Bronze/bronze) Ni (Nickel/nickel) PA PA Stahl (UQST 36-2 4.8) vernickelt/steel nickel plated
10 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology +2 –1 ~ 2 ~ 1 P10 40 ~ 50 M3 33 27 18 1 2 3 +2 –1 ~ 2 ~ 1 P10 40 ~ 50 27 18 1 2 3 33 M3 Polzahl Contacts Kabeldurchlass Cable outlet Schaltung Wiring Strom Rated current Bestell-Nr. Ordering-No. 2+PE 6–8 mm P10 230 V 2 A 43 1726 110 03 Polzahl Contacts Kabeldurchlass Cable outlet Schaltung Wiring Strom Rated current Bestell-Nr. Ordering-No. 2+PE 8–10 mm P10 230 V 2 A 43 1726 112 03 Gerätesteckdose DIN EN 175301-803, hohes Gehäuse, beschaltet Female power connector DIN EN 175301-803, high housing, wired Gerätesteckdose DIN EN 175301-803, hohes Gehäuse, beschaltet Female power connector DIN EN 175301-803, high housing, wired 210 Bauform A 2+PE Zentralschraube/central screw (40 cNm) schrauben/screw (40 cNm) max. 1,5 mm2 (max. AWG 16) 6–8 mm, 8–10 mm IP40 ohne Dichtung/without sealing, IP65 mit Dichtung siehe Zubehör/with sealing see accessories > 50 Steckzyklen/> 50 mating cycles + 85 °C – 25 °C 230 V 4000 V 3 IIl lll 2 A CuSn (Bronze/bronze) Ni (Nickel/nickel) PA PA Stahl (UQST 36-2 4.8) vernickelt/steel nickel plated
11 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology Polzahl Contacts Kabeldurchlass Cable outlet Schaltung Wiring Strom Rated current Bestell-Nr. Ordering-No. 2+PE 6–8 mm E6 24 V 10 A 43 1714 135 03 P33 110 V 10 A 43 1714 133 03 P30 230 V 10 A 43 1714 131 03 8–10 mm E6 24 V 10 A 43 1714 136 03 P33 110 V 10 A 43 1714 134 03 P30 230 V 10 A 43 1714 132 03 Polzahl Contacts Kabeldurchlass Cable outlet Schaltung Wiring Strom Rated current Bestell-Nr. Ordering-No. 2+PE 6–8 mm P40 230 V 2 A 43 1730 140 03 8–10 mm 2 A 43 1730 142 03 3+PE 6–8 mm P45 24 V 10 A 43 1732 145 04 8–10 mm 10 A 43 1732 146 04 Gerätesteckdose DIN EN 175301-803, niedriges Gehäuse, beschaltet, LED Female power connector DIN EN 175301-803, low housing, wired, LED Gerätesteckdose DIN EN 175301-803, hohes Gehäuse, beschaltet, LED Female power connector DIN EN 175301-803, high housing, wired, LED 210 Bauform A 2+PE 3+PE Zentralschraube/central screw (40 cNm) schrauben/screw (40 cNm) max. 1,5 mm2 (max. AWG 16) 6–8 mm, 8–10 mm IP40 ohne Dichtung/without sealing, IP65 mit Dichtung siehe Zubehör/with sealing see accessories > 50 Steckzyklen/> 50 mating cycles + 85 °C – 25 °C 24 V, 110 V, 230 V E6/P45: 800 V, P33: 2500 V, P30/P45: 4000 V 3 IIl lll 2 A, 10 A CuSn (Bronze/bronze) Ni (Nickel/nickel) PA PC Stahl (UQST 36-2 4.8) vernickelt/steel nickel plated 40 ~ 50 M3 27 18 26,5 ~+ 1 — 2 LED (rot/red) E6 P33 P30 1 2 3 40 ~ 50 M3 27 18 33 P40 P45 1 2 3 LED gelb/yellow +2 –1 ~ 2 ~ 1 1 2 PE 3 N LED gelb/yellow LED grün/green 1 2 PE 3
12 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology Polzahl Contacts Bestell-Nr. Ordering-No. 2+PE 99 5700 00 03 3+PE 99 5702 00 04 Adapter, hohes Gehäuse, Gerätesteckdose DIN EN 175301-803, M12 Adapter, high housing, female power connector DIN EN 175301-803, M12 210 Bauform A 2+PE 3+PE Zentralschraube/central screw (40 cNm) schrauben (40 cNm), löten/screw (40 cNm), solder — — IP65 > 50 Steckzyklen/> 50 mating cycles + 85 °C – 30 °C 250 V 800 V 3 II ll 4 A CuSn (Bronze/bronze)/CuZn (Messing/brass) Ni (Nickel/nickel), Au (Gold/gold) PA PA Stahl (UQST 36-2 4.8) vernickelt/steel nickel plated 40 2,1 ~ 54 26,5 M12 x 1 6,8 M3 18 1,2 1,2 2,5 5,3 20 MSD 3 1 2 3 27
13
14 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology Polzahl Contacts Bestell-Nr. Ordering-No. 2+PE 43 1705 000 03 43 1705 009 03 vergoldete Kontakte/gold plated contacts 3+PE 43 1707 000 04 43 1707 009 04 vergoldete Kontakte/gold plated contacts Polzahl Contacts Bestell-Nr. Ordering-No. 2+PE 43 1705 005 03 43 1705 019 03 vergoldete Kontakte/gold plated contacts 3+PE 43 1707 005 04 43 1707 019 04 vergoldete Kontakte/gold plated contacts Polzahl Contacts Bestell-Nr. Ordering-No. 2+PE 43 1701 000 03 3+PE 43 1703 000 04 210 Bauform A 2+PE 3+PE Zentralschraube/central screw (40 cNm) löten/solder max. 1,0 mm2 (AWG 18) — IP40 ohne Dichtung/without sealing, IP65 mit Dichtung siehe Zubehör/with sealing see accessories > 50 Steckzyklen/> 50 mating cycles + 125 °C – 40 °C 250 V 4000 V 3 IIl lll 10 A CuSn (Bronze/bronze), Au (Gold/gold) Sn (Zinn/tin) PA — CuZn (Messing/brass) Gerätestecker DIN EN 175301-803, rund Male circular power connector DIN EN 175301-803 Gerätestecker DIN EN 175301-803, rund, Überwurfmutter M27 x 1,5 Male circular power connector DIN EN 175301-803, coupling ring M27 x 1.5 Gerätestecker DIN EN 175301-803, rund Male circular power connector DIN EN 175301-803 27 18 10 12 24,5 18 10 12 8,6 1 2 3 32 18 10 12 10,5 Ø 34 1 2 3
15 Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Automatisierungstechnik Automation Technology 29,6 18 10 12 3 2 1 8,5 6,4 18,25 Polzahl Contacts Bestell-Nr. Ordering-No. Radius Radius Index Index 2+PE 43 1717 xxx 03 17 mm 021 20 mm 022 22 mm 023 25 mm 024 28 mm 025 3+PE 43 1719 xxx 04 31 mm 026 35 mm 027 41 mm 028 45 mm 029 51 mm 030 Polzahl Contacts Bestell-Nr. Ordering-No. 2+PE 43 1709 000 03 3+PE 43 1711 000 04 Polzahl Contacts Bestell-Nr. Ordering-No. 2+PE 43 1713 000 03 3+PE 43 1715 000 04 210 Bauform A 2+PE 3+PE Zentralschraube/central screw (40 cNm) löten/solder max. 1,0 mm2 (AWG 18) — IP40 ohne Dichtung/without sealing, IP65 mit Dichtung siehe Zubehör/with sealing see accessories > 50 Steckzyklen/> 50 mating cycles + 125 °C – 40 °C 250 V 4000 V 3 IIl lll 10 A CuSn (Bronze/bronze), Au (Gold/gold) Sn (Zinn/tin) PA — CuZn (Messing/brass) Gerätestecker DIN EN 175301-803, quadratisch, 2 Befestigungslöcher Male rectangular power connector DIN EN 175301-803, 2 mounting holes Gerätestecker DIN EN 175301-803, quadratisch, 4 Befestigungslöcher Male rectangular power connector DIN EN 175301-803, 4 mounting holes Gerätestecker DIN EN 175301-803, quadratisch, Radius Male rectangular power connector DIN EN 175301-803, radius 29,6 18 10 12 3 2 1 11,6 R 29,6 18 12 3 2 1 8,5 6,4 18,25 10
16 1) Vergleichbare AWG Leiter siehe technische Informationen./ 1) Comparable AWG conductors see technical information. Polzahl Number of contacts Steckverbinder Verriegelung Connector locking system Anschlussart Termination Anschlussquerschnitt Wire gauge Kabeldurchlass Cable outlet Schutzart Degree of protection Mechanische Lebensdauer Mechanical operation Obere Grenztemperatur Upper temperature Untere Grenztemperatur Lower temperature Bemessungsspannung Rated voltage Bemessungs-Stoßspannung Rated impulse voltage Verschmutzungsgrad Pollution degree Überspannungskategorie Overvoltage categorie Isolierstoffgruppe Material group Bemessungsstrom (40°C) Rated current (40 °C) Material Kontakt Material of contact Kontaktoberfläche Contact plating Material Kontaktkörper Material of contact body Material Gehäuse Material of housing Material Verriegelung Material of locking Technische Daten Kabel Specifications of cable Querschnitt mm2 1) Wire gauge mm2 1) Material Mantel Material jacket Isolation Litze Insulation wire Litzenaufbau (mm) Design of wire (mm) Kabelmantel Ø (mm) Cable jacket Ø (mm) Leiterwiderstand Resistance of wire Temp.-Bereich (Kabel bew.) Temp. range (cable in move) Temp.-Bereich (Kabel fest) Temp. range (cable fixed) Biegeradius (Kabel bew.) Bending radius (cable in move) Biegeradius (Kabel fest) Bending radius (cable fixed) Zulassung Approval Automatisierungstechnik Automation Technology Magnetventilsteckdose DIN EN 175301-803, niedriges Gehäuse, umspritzt Female solenoid valve connector DIN EN 175301-803, low housing, moulded Magnetventilsteckdose DIN EN 175301-803, niedriges Gehäuse, umspritzt, beschaltet, LED Female solenoid valve connector DIN EN 175301-803, low housing, moulded, wired, LED 210 Bauform A 2+2PE 3+PE Zentralschraube/central screw (40 cNm) schneidklemm, am Kabel angespritzt/IDT connection, moulded 0,75 mm2 (AWG 18) — IP67 > 50 Steckzyklen/> 50 mating cycles (fest verlegt/for stationary use) + 80 °C (fest verlegt/for stationary use) – 25 °C 230 V, 24 V Z10/Z20: 800 V, andere/others: 4000 V 3 IIl l 10 A, 4 A CuSn (Bronze/bronze) Ag (Silber/silver) PBT PBT Stahl verzinkt/galvanised steel 45 30 L 27 50 45 30 L 27 50 Z10 1 2 schwarz 1/black 1 schwarz 2/black 2 grün/gelb green/yellow V2 R V1 schwarz 1/black 1 schwarz 2/black 2 grün/gelb green/yellow yellow Z20 1 2 schwarz 1/black 1 schwarz 2/black 2 grün/gelb green/yellow 1 2 2+2PE schwarz 1/black 1 schwarz 2/black 2 grün/gelb green/yellow 1 2 3 schwarz 3/black 3 3+PE 3 4 — PUR PVC 24 x 0,2 Cu (Kupfer/copper) 6 26 Ω/Km (20 °C) – 5 °C /+ 70 °C – 25 °C /+ 70 °C min. 60 mm min. 30 mm — Polzahl Contacts Kabelmantel Cable jacket Spannung Voltage Strom Current Kabellänge Cable length Bestell-Nr. Ordering-No. 2+2PE PUR 230 V 10 A 3 m 31 5234 300 000 5 m 31 5234 500 000 3+PE PUR 230 V 10 A 3 m 31 5235 300 000 5 m 31 5235 500 000 Polzahl Contacts Kabelmantel Cable jacket Schaltung Wiring Strom Current Kabellänge Cable length Bestell-Nr. Ordering-No. 2+2PE PUR Z10 24 V 4 A 3 m 31 5236 300 510 5 m 31 5236 500 510 Z20 24 V 4 A 3 m 31 5237 300 520 5 m 31 5237 500 520
17
18 Automatisierungstechnik Automation Technology 210 Montageanleitung Assembly instruction Gerätesteckdose Female power connector Bauform A Gerätesteckdose mit Zugentlastung Female power connector with strain relief Polbilder Contact arrangements 2+PE pol/3+PE pol 2+PE contacts/ 3+PE contacts 1 2 18 3 2+2PE pol, PE gebrückt 2+2PE contacts, PE connected protective earth 3+PE pol 3+PE contacts 2+2PE 1 schwarz 1/black 1 2 schwarz 2/black 2 3 grün/gelb/green/yellow 4 grün/gelb/green/yellow 2 1 18 3/ 4/ 18 3+PE 1 schwarz 1/black 1 2 schwarz 2/black 2 3 schwarz 3/black 3 4 grün/gelb/green/yellow 4/ 3 2 1
19 Zubehör Automatisierungstechnik Accessories Automation Technology 210 Bauform A Material / Material Farbe / Colour Temp.bereich / Temp. range Bestell-Nr. / Ordering-No. NBR beige/beige – 40 °C /+ 100°C 16 8085 000 Silicon rot/red – 60 °C /+ 230°C 16 8085 001 NBR beige/beige – 40 °C /+ 100°C 16 8090 000 Silicon rot/red – 60 °C /+ 230°C 16 8090 001 NBR beige/beige – 40 °C /+ 100°C 16 8089 000 Silicon rot/red – 60 °C /+ 230°C 16 8089 001 NBR beige/beige – 40 °C /+ 100°C 16 8092 000 Silicon rot/red – 60 °C /+ 230°C 16 8092 001 NBR schwarz/black – 30 °C /+ 125°C 16 8088 000 NBR schwarz/black – 20 °C /+ 120°C 16 8114 000 PA schwarz/black — 02 8191 000 Bezeichnung / Description Maßzeichnung / Drawing Flachdichtung Flat seal Flachdichtung Flat seal Flachdichtung Flat seal Flachdichtung Flat seal Profildichtung Profiled seal Profildichtung Profiled seal Überwurfmutter Coupling ring Rändelschraube Knurled screw 18 27 R3 1,5 2,5 2 Ø 8,5 1,1 1,1 27 6,7 18 5,2 1,5 R4,5 8 18,25 R 30 24,5 Ø 5,8 16,5 22 1,5 18,3 29 8 R Ø 5,8 Ø 2,4 1,5 R4,5 8 R 30 24,5 34 R3 1,5 26,5 R4,5 R2 4,5 R1 R1 29 29,5 23 R3 Ø 21 1,5 4,5 R4,5 R1 R1 29,5 29 26,5 32 R41,5 Ø 34 Ø 21,8 10,5 M27 x 1,5 29,1 1,5 Ø7 2,2 M3 Ø 13 7,5 3,5 35,1 1,5 Ø7 2,2 M3 Ø 13 7,5 4 Länge / Length Bestell-Nr. / Ordering-No. 29,1 mm 16 8096 131 35,1 mm 16 8104 131
